AREA FLOW METER

KNR type flow meter

KNR type flow meter

  1. This is used as a glass taper tube flow meter for measuring the tiny flow rate of gas and liquid by attaching it to a panel, directly attaching it to a pipe, or attaching it to a stand, in order to monitor the flow rate of analysis equipment and measurement gauge.
Type Without valve: KNR-100,KNR-1125,KNR-1150,KNR-1175,KNR-3100,KNR-4000,
KNR-5000
Without valve: KNR-100V,KNR-1225,KNR-1250,KNR-1275,KNR-3200
Bore RC-1/8,RC-1/4,RC-1/2
Flow rate *RC-1/8
Without valve With valve
Gas KNR-100, 30 to 300Ncc/min Liquid KNR-1125, 5 to 50cc/min
KNR-1125, 150 to 1500Ncc/min KNR-1150, 5 to 50cc/min
KNR-1150, 150 to 1500Ncc/min KNR-1175, 20 to 200cc/min
KNR-1175, 0.5 to 5NL/min

*RC-1/4
Gas KNR-3100, 10 to 100NL/min Liquid KNR-3100, 0.3 to 3L/min
KNR-4000, 10 to 100NL/min KNR-4000, 0.3 to 3L/min

*RC-1/2
Gas KNR-5000、30 to 300NL/min Liquid KNR-5000、2.5 to 25L/min
Withstanding pressure 1.0MPa
Temperature 60°C or less
Accuracy ±2%FS
Material Main unit : C3604B, DURACON, PVC
Float : SUS304, carvone, glass
Taper tube : hard glass, Pyrex
